ICQ Compact Air Cylinder

SKU:
Availability:
Inquire Add to Basket

FEATURES

1、 Implement of JIS Standard;

2、 Piston using special both way sealing structure with tight dimension and the function of oil storage;

3、 Rear cap& cylinder body, piston rod& piston using impact reliably riveting structure;

4、 Using rubber buffer gasket to reducing impact;

5、 Compact type structure can effectively save space;

6、 The body with magnet groove, easy to install the magnet;

7、 Various type of cylinder for choosing.




Bore size (mm) 12 16 20 25 32 40 50 63 80 100
Action Double acting type
Fuild Air(filtered through 40μ filter element)
Operating pressure 0.1~0.9Mpa(1-9kgf/cm²)
Proof pressure 1.35Mpa(13.5kgf/cm²)
Ambient & fluid temperature -5~70℃
Cushion Rubber cushion
Port size M5 G1/8'' G1/4'' G3/8''
Body Material Aluminum alloy
